R0.2 Special Angle Rectangle Flat Retractable Cable

Brand Name : Spiral Cable

Model Number : TH-800119

Certification : UL, CUL, CSA, AWM, CE

Place of Origin : Dongguan, China

MOQ : 200 PCS

Price : USD0.12~0.52 per piece

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 800,000pcs per month

Delivery Time : 10 days for ready goods

Packaging Details : 200pcs per carton box

Type : Retractable Cable

Feature : R0.2 Special Angle Design

Rated Temperature : 80 degree

Rated Voltage : 300V

Dimensions : To be customized per request

Standard : RoHS Compliant

Contact Now

R0.2 Special Angle Rectangle Flat Retractable Cable

Retractable Cable is one of Tongheng main products. R0.2 Special Angle Rectangle Flat Retractable Cable can be customized exactly following customers requirement. As the professional manufacturer, Tongheng staff engage to present customer the best quality article. R0.2 Special Angle Rectangle Flat Retractable Cable is one of the excellent example. Its remarkable advantage is R0.2 special angle design.

Here below is the product properties:

Special R0.2 angle customized.

Pure copper wire strands conductors.

Standard: UL758, CSA22.2

To be customized per customer request.

Product parameters:

Retractable Cable Conductor Structure Insulation Thickness Nominal Diameter Screened Coverage Sheath Thickness Overall Diameter Conductor Resistance
No/mm mm mm % mm mm Ω/KM(20℃)
2C 7/0.100 0.76 1.90 ≥65 1.15 6.70 381.00
2C 7/0.127 0.76 2.00 ≥65 1.15 7.00 239.00
2C 7/0.16 0.76 2.10 ≥65 1.15 7.10 150.00
2C 11/0.16 0.76 2.20 ≥65 1.15 7.30 94.20
2C 17/0.16 0.76 2.40 ≥65 1.15 7.70 59.40
2C 21/0.178 0.76 2.50 ≥65 1.15 8.10 36.70
2C 34/0.178 0.76 2.80 ≥65 1.15 8.70 23.20
2C 26/0.25 0.76 3.10 ≥65 1.15 10.90 14.60
3C 7/0.100 0.76 1.90 ≥65 1.15 8.60 381.00
3C 7/0.127 0.76 2.00 ≥65 1.15 8.80 239.00
3C 7/0.16 0.76 2.10 ≥65 1.15 9.00 150.00
3C 11/0.16 0.76 2.20 ≥65 1.15 9.20 94.20
3C 17/0.16 0.76 2.40 ≥65 1.15 9.60 59.40
3C 21/0.178 0.76 2.50 ≥65 1.15 10.10 36.70
3C 34/0.178 0.76 2.80 ≥65 1.15 10.70 23.20
4C 7/0.100 0.76 1.90 ≥65 1.15 8.80 381.00
4C 7/0.127 0.76 2.00 ≥65 1.15 9.00 239.00
4C 7/0.16 0.76 2.10 ≥65 1.15 9.30 150.00
4C 11/0.16 0.76 2.20 ≥65 1.15 9.60 94.20
4C 17/0.16 0.76 2.40 ≥65 1.15 10.00 59.40
4C 21/0.178 0.76 2.50 ≥65 1.15 10.50 36.70
5C 7/0.100 0.76 1.90 ≥65 1.15 9.10 381.00
5C 7/0.127 0.76 2.00 ≥65 1.15 9.40 239.00
5C 7/0.16 0.76 2.10 ≥65 1.15 9.50 150.00
5C 11/0.16 0.76 2.20 ≥65 1.15 9.90 94.20
5C 17/0.16 0.76 2.40 ≥65 1.15 10.60 59.40
6C 7/0.100 0.76 1.90 ≥65 1.15 9.50 381.00
6C 7/0.127 0.76 2.00 ≥65 1.15 9.80 239.00
6C 7/0.16 0.76 2.10 ≥65 1.15 10.10 150.00
6C 11/0.16 0.76 2.20 ≥65 1.15 10.40 94.20

Contact:

Thanks for your visit to our website. The above displayed parameters are just for reference. Please ask us for customized ones immediately if you have the differentt requirement.

R0.2 Special Angle Rectangle Flat Retractable Cable


Wholesale R0.2 Special Angle Rectangle Flat Retractable Cable from china suppliers

R0.2 Special Angle Rectangle Flat Retractable Cable Images
